A Level Mathematics: Mechanics Practice Questions (Cambridge 9709 Paper 4)
Original exam-style Cambridge 9709 Paper 4 Mechanics questions with worked answers on work, power, momentum, kinematics, friction and energy methods.
- Subject
- Mathematics
- Level
- A LEVELS
- Topic
- Mechanics
- Author
- Marlbridge Academic Team
- Updated
- Reviewed by
- Sajawal Zahid (what this means)
Aligned to Cambridge A Level Mathematics (9709), 2026-2027. Official specification .
Syllabus page (what it covers and how it is assessed): Cambridge A Level Mathematics.
Syllabus points this page covers
9709
- 4.1 Forces and equilibrium
- 4.2 Kinematics of motion in a straight line
- 4.3 Momentum
- 4.4 Newton's laws of motion
- 4.5 Energy, work and power
This page covers all 5 subtopics recorded here in topic 4, Mechanics.
Found an error? Report a correction.
Need help with this topic? Request a free trial class for A Level Mathematics (9709).
These are original questions written for Marlbridge, for revision and practice on this content. They are not reproduced past-paper questions, and they do not replicate the exam’s exact structure, question count or mark tariffs — Cambridge International holds copyright in its own papers. Use these alongside the official past papers available from your board.
Take g = 10 m s⁻². Each question practises a skill tested in the June 2025 Paper 4 series. After each answer there is a tip and the real question to try next.
Questions
1. A box is pushed in a straight line along horizontal ground by a force of 40 N acting at 30° above the horizontal. The box moves 15 m in 6 seconds at constant speed. (a) Find the speed of the box. (b) Find the work done by the 40 N force. (c) Find the power of the 40 N force. [4]
2. Particles P and Q, of masses 0.3 kg and 0.2 kg, move in the same direction along a straight line on a smooth horizontal surface. P moves at 4 m s⁻¹ and Q moves at 1.5 m s⁻¹ ahead of it. P catches up with Q and the two particles coalesce. Find the kinetic energy lost in the collision. [4]
3. A car passes a point A at 12 m s⁻¹. It accelerates uniformly at 0.5 m s⁻² for 20 s, then decelerates uniformly at 0.4 m s⁻² until it stops at a point B. Find the distance AB. [4]
4. Particle A, of mass 2 kg, is on a rough horizontal table. It is attached by a light inextensible string, which passes over a small smooth pulley at the edge of the table, to particle B, of mass 3 kg, which hangs freely. The system is released from rest and B accelerates downwards at 4 m s⁻². Find the tension in the string and the coefficient of friction between A and the table. [4]
5. A particle P moves in a straight line. Its velocity t seconds after leaving a point O is v = 6t − t² + 7 m s⁻¹, for 0 ≤ t ≤ 5.
(a) Find the maximum velocity of P.
(b) Find the distance of P from O when it reaches this maximum velocity. [4]
6. A particle of mass 5 kg rests on a rough plane inclined at 30° to the horizontal. The coefficient of friction is 0.2. A force P N acting up the plane, parallel to a line of greatest slope, keeps the particle from sliding down. Find the least possible value of P. [4]
7. A particle of mass 2 kg is projected at 6 m s⁻¹ up a line of greatest slope of a rough plane inclined at 30° to the horizontal. The friction force has magnitude 5 N. Using an energy method: (a) find the distance the particle travels up the plane before it comes to rest (b) find its speed when it returns to its starting point. [6]
Answers
1. (a) 15 ÷ 6 = 2.5 m s⁻¹ [1]. (b) Work done = 40 cos 30° × 15 [1] = 520 J (3 s.f.) [1]. (c) Power = 40 cos 30° × 2.5 = 86.6 W [1].
Tip: only the component of the force in the direction of motion does work.
Try the real question next: Cambridge International AS & A Level Mathematics 9709, June 2025, Paper 42, Question 1.
2. Momentum: 0.3 × 4 + 0.2 × 1.5 = 0.5v [1], so v = 3 m s⁻¹ [1]. KE before = ½(0.3)(16) + ½(0.2)(2.25) = 2.625 J; KE after = ½(0.5)(9) = 2.25 J [1]. KE lost = 0.375 J [1].
Tip: decide one positive direction first. Here both particles move the same way, so both velocities are positive.
Try the real question next: Cambridge International AS & A Level Mathematics 9709, June 2025, Paper 42, Question 2.
3. After 20 s: v = 12 + 0.5 × 20 = 22 m s⁻¹ [1]. Distance while accelerating = 12 × 20 + ½ × 0.5 × 20² = 340 m [1]. Distance while decelerating: 0 = 22² − 2 × 0.4 × s, so s = 605 m [1]. AB = 945 m [1].
Tip: sketch the velocity–time graph first; the distance is the area under it.
Try the real question next: Cambridge International AS & A Level Mathematics 9709, June 2025, Paper 42, Question 4.
4. For B: 30 − T = 3 × 4, so T = 18 N [2]. For A: 18 − F = 2 × 4, so F = 10 N [1]. R = 20 N, so μ = 10 ÷ 20 = 0.5 [1].
Tip: write Newton’s second law for each particle separately, with the tension acting on both.
Try the real question next: Cambridge International AS & A Level Mathematics 9709, June 2025, Paper 42, Question 5.
5. (a) dv/dt = 6 − 2t = 0 when t = 3 [1]. v = 18 − 9 + 7 = 16 m s⁻¹ [1]. (b) s = ∫₀³ (6t − t² + 7) dt = [3t² − t³/3 + 7t]₀³ [1] = 27 − 9 + 21 = 39 m [1].
Tip: for maximum velocity, differentiate v and set the acceleration to zero.
Try the real question next: Cambridge International AS & A Level Mathematics 9709, June 2025, Paper 42, Question 6.
6. R = 50 cos 30° = 43.3 N [1]. The particle is about to slide down, so friction acts up the plane: F = 0.2 × 43.3 = 8.66 N [1]. Resolving along the plane: P + 8.66 = 50 sin 30° = 25 [1], so P = 16.3 N [1].
Tip: friction always opposes the motion that would happen, so decide which way the particle would slide.
Try the real question next: Cambridge International AS & A Level Mathematics 9709, June 2025, Paper 42, Question 5(b).
7. (a) Going up a distance d, the particle gains PE 2 × 10 × d sin 30° = 10d and does 5d of work against friction [1]. ½ × 2 × 6² = 36 = 10d + 5d [1], so d = 2.4 m [1]. (b) Coming down, PE lost = 10 × 2.4 = 24 J and work against friction = 5 × 2.4 = 12 J [1]. KE at the start = 24 − 12 = 12 J [1], so ½ × 2 × v² = 12 and v = 3.46 m s⁻¹ [1].
Tip: friction takes energy away in both directions, so the particle returns more slowly than it left.
Try the real question next: Cambridge International AS & A Level Mathematics 9709, June 2025, Paper 42, Question 7.
Where marks are usually lost
- The full force, rather than its component, used for work done.
- Velocities given the wrong sign in momentum questions.
- Friction drawn the wrong way on an inclined plane.
- Maximum velocity found by setting v = 0 instead of dv/dt = 0.
Frequently asked questions
What topics come up on Cambridge 9709 Paper 4 Mechanics? These practice questions cover work and power, momentum and collisions, kinematics with constant and variable acceleration, connected particles over a pulley, friction on an inclined plane, and energy methods.
What value of g should you use in 9709 Mechanics? These questions take g = 10 m s⁻², which is the value used in Cambridge 9709 Mechanics questions unless a question states otherwise.
How do you find the work done by a force at an angle? Only the component of the force in the direction of motion does work, so multiply that component (for example F cos θ) by the distance moved, not the full force.
How do you find the maximum velocity when v is given as a function of t? Differentiate v to get the acceleration and set dv/dt = 0, then substitute that time back into v. Setting v = 0 instead is a common mistake.
Which way does friction act on a particle on a slope? Friction opposes the motion that would happen, so first decide which way the particle would slide. If it is about to slide down, friction acts up the plane.
